Product Details:
|
| Mateiral: | PE, PP, Nylon | Usage: | Liquid Filter |
|---|---|---|---|
| Appliation: | Water , Liquid Filteration | Sizes: | Standard #1~#5, Accept Customized |
| Micron Rating: | 0.5-200um, 5 10 25 50 75 100 150 200 300 400 500 Micron, 20-800, 0.5, 10um | Body Construction: | S(Sewn).W(Welded), Sewn/Welded |
| Bag Top Ring: | Plastic Ring, Stainless Steel Ring | Bag Sizes: | 1#, 2#, 3#, 4#, #1-#5 Filter Bag Or Customized |
| Ring: | PP, PVC, Stainless Steel, Plastic And Metal Ring | Bag Top Type: | H Ring, F Ring, SS Ring, ETC., Ring And String |
Micro filtration filter bag
Polyester micro filter bag, PE micro filter bag, Micro filter bag,5 micro filter bag,10 micro filter bags,PP micro filter bag,nylon micro filter bag,ptfe micro filter bag,stainsteel micro filter bag and micro filter felt from 0.2 micro to 600micro and so on.
Liquid filter bag housing
Liquid filtration and seperatin products
Bag filter system
Cartridge filter system
Pipe filters system
Self cleaning filters system
Auto back-flush self cleaning filter system
Filter cartridges system
Specification of liquid filter bag
| Fiber | Abrasion resistance | Weakly acid | Strongly acid | Weakly alkali | Strongly alkali | Solvent | Temperature (°C) |
| PE | Very good | Very good | Good | Good | Poor | Good | 130-150 |
| Nylon | Excellent | General | Poor | Excellent | Excellent | Good | 135-149 |
| PP | very good | Excellent | Excellent | Excellent | Excellent | General | 90-110 |
Filter bags Specifications |
|
| Filter Media | nylon Felt, polyester Felt, polypropylene |
| Maximum Operating Temperature | Polypropylene: 200-220° F (93-104° C) Polyester: 275-325° F (135-162° C) Nylon: 275-300° F (135-149° C) |
| Micron Rating | Polypropylene: 0.5, 1, 3, 5, 10, 25, 50, 100, 200 Polyester: 0.5, 1, 3, 5, 10, 25, 50, 75, 100, 200 Nylon: 25, 50, 100, 150, 200, 300, 400, 500, 600 |
| Size | 1: 7" x 16" (17.78 cm x 40.64 cm) 2: 7" x 32" (17.78 cm x 81.28 cm) 3: 4" x 8.25" (10.16 cm x 20.96 cm) 4: 4" x 14" (10.16 cm x 35.56 cm) 5: 6 " x 22" (15.24 cm x 55.88 cm) |
| Collar Ring | Polypropylene ring Polyester ring galvanized steel ring Stainless steel ring Rope |
| Remarks | The length of filter bags can be customized. If your filter bag is different from our filter bag size, please send us your drawing size and the material which you need, we also produce the nonstandard filter bag. |
| Please send us you inquiry specification detail by email for quote, thanks. | |
Advantages of Liquid Filter Bag
1. Inside-outside flow configuration : It can capture contaminants effectively on the inside.
2. Plastic or steel seal : It is necessary and helpful for prevention of fluid bypass and subsequent contamination of the downstream fluid. All of our good performance filter bags are provided in both plastic and steel ring sealing collar versions that will be fit for most filter bag manufactures' housings.
3. Welded seams and thermally treated exterior surfaces It is efficient for control of fiber migration.
4. Our material has the special ability to handle viscous fluids.
Producing Process(Air Filter Bag and Liquid Filter Bag):
Applications:
