Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy

Certification
China Riqi ( Hangzhou ) Filter Technology Co., Ltd. certification
China Riqi ( Hangzhou ) Filter Technology Co., Ltd. certification
I'm Online Chat Now

Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy

Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy
Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy

Large Image :  Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy

Product Details:
Place of Origin: China
Brand Name: RQ
Payment & Shipping Terms:
Minimum Order Quantity: 50m2
Price: 1.1usd to 25usd/m2
Packaging Details: standard export packing
Delivery Time: 5-15days
Payment Terms: T/T, L/C
Supply Ability: 5000m2/day

Polyester Air Slide Fabric for Cement Plant, Chemical Industry and Metallurgy

Description
Material: Polyester Thickness: 4mm, 4.5mm , 5mm, 6mm
Application: Cement

Polyester Air Slide Fabric For Cement Plant , Chemical Industry And Metallurgy
Air slide Fabrics

In cement plant:


An Airslide belt is in the middle of a chute. Powder material will come into the chute above Airslide belt. Material will flow to the chute lower side as pneumatic blower down Airslide belt. That's why we say Airslide belt can move powder material because of the wind power. And then, the rest wind will go out from the top of the chute. Through the moving, no parts moved except powder material. So that it can spare more energy and maintain cost, etc.



fluidization silo:


Our Airslide canvas is installed on the surface of the silo bottom. It is supplied for installation as aeration units on the sloped conical bottoms of bins and silos to aid in the withdrawal of dry relatively free-flowing material.

Each Airslide aeration unit package consists of 200mm open-type. Airslide conveyor units in lengths of 1.5 or 3m depend on the slope length of the conical storage area. Some spoke patterns are normally used with materials which have good fluidization characteristics. Others spoke patterns provide maximum aeration for difficult materials which can be fluidized.



Specifications:

TYPE MATERIAL PLY TENSILE STRENGTH HEAT RESISTANCE ºC THICKNESS WEIGHT/m2 MAX WIDTH AIR RESISTANCE IN
WARP >N/mm WEFT >N/mm 2m3/m2/minH2O mm
AP4-4 100%Polyester 4 360 270 150 4 3200g 2000mm Type A;80-120
Type B:120-150
Type C:150-200
AP4-5 100%Polyester 4 360 270 150 5 3600g 2000mm Type A;80-120
Type B:120-150
Type C:150-200
AP4-6 100%Polyester 4 360 270 150 6 4000g 2000mm Type A;80-120
Type B:120-150
Type C:150-200
AP4-7 100%Polyester 4 360 270 150 7 4400g 2000mm Type A;80-120
Type B:120-150
Type C:150-200
AP4-8 100%Polyester 4 360 270 150 8 4800g 2000mm Type A;80-120
Type B:120-150
Type C:150-200
AC4-5 100%Cotton 4 150 100 150 5 3800g 2000mm Type A;80-120
Type B:120-150
Type C:150-200

Polyester Filament Air Slide Fabric For Cement Factory

The Polyester Filament Air Slide Fabric For Cement Factory consists of polyester fiber as raw material, which is woven by heavy-duty loom warp and weft thread,it is suitable for pneumatic transportation of powdery materials such as cement and alumina. The product is spread between the material and the air chamber, the following is the gas chamber, the above is the material, under the action of air pressure through the product, the material fluidized, so as to achieve the purpose of transport. It is also suitable for pneumatic conveying devices of other powder and granular materials.

Polyester Filament Air Slide Fabric For Cement Factory Advantage
No moisture absorption No caking
Resistant to rotting and decomposition
Complete unloading without residues
Consistent fluidization over the complete surface
Good resistance to abrasion
Low wear and therefore longer life
Low shrinkage even when used under hot and humid conditions.
