Aramid Filter Bag for Asphalt Plant Dust Collector

Certification
China Riqi ( Hangzhou ) Filter Technology Co., Ltd. certification
China Riqi ( Hangzhou ) Filter Technology Co., Ltd. certification
I'm Online Chat Now

Aramid Filter Bag for Asphalt Plant Dust Collector

Aramid Filter Bag for Asphalt Plant Dust Collector

Description
Supply Ability: 5000PCS / Week Model NO.: PH00240
Filtration Grade: HEPA Filter Filter Bag Sectional Shape: Round Bag
Filter Bag Environment: High-Temperature Cartridge Installation: Vertical Lifting
Working Temperature: 240 Anti Acidic: Good
Anti Alkaline: Excellent Transport Package: Standard Export Packing
Specification: 1m X 1m X 1m Trademark: Philis
Origin: China HS Code: 5911900
Material: Non-woven Medium Material: Nomex
Cartridge Filter: Aramid Fiber Filter Bag Filter: The Filter Type
Type: House Filter Bag Usage: Dust Filter, Air Filter
Samples: US$ 0/Square Meter 1 Square Meter(Min.Order) | Requ Customization: Available | Customized Request

Product Description

Company Info.

Customer Question & Answer
Ask something for more details

Basic Info.

Model NO.
PH00240
Filtration Grade
HEPA Filter
Filter Bag Sectional Shape
Round Bag
Filter Bag Environment
High-Temperature
Cartridge Installation
Vertical Lifting
Working Temperature
240
Anti Acidic
Good
Anti Alkaline
Excellent
Transport Package
Standard Export Packing
Specification
1m x 1m x 1m
Trademark
philis
Origin
China
HS Code
5911900
Production Capacity
5000PCS / Week

Product Description

industrial filter bag for dust collector

Polyester(PET/PE/PES) filter bag is the main filter material in bag filter.use world-class nonwovens needling technology to carve and lay up polyester staple fiber, then needle the finely woven fabric and evenly distributed fabric into felt. The filter media has strong strength, good resilience, stable fabric size, good abrasion resistance, large porosity, good air permeability, long service life and good dedusting filtration.Below 130 degree C It has good mechanical, acid and alkali resistance properites.

Polyester needle felt is the most cost-effective medium at low temperature.

Compared with the general woven filter, polyester needling dust filter bag has the following advantages:

1. Large porosity and good air permeability improved the load capacity of the equipment and reduce the pressure and energy consumption.
2.Huge dust removal efficiency and low emission. The experimental results that the efficiency of filtering 325 mesh slide stone powder (diameter of 7.5 um) can reach 99.9-99.99%, the gas emission is much more lower than national standard.
3. Finishes by hot set, singe, PTFE membrane, glazed.
Smooth surface and easy cake release,the service life is generally 1 ~ 5 times longer than woven filter cloth.
4.Chemical stability, not only good at high temperature gas filtration, but also suitable for acid and alkali including erosive gas.

Application:

Polyester filter media is widly used in cement grinding process,  wood processing factory, smelting factory and other industries at the temperature lower than 130degree C.

Durling the processing of dust collector, if the gas or dust contain to much moisture and oil, including hygroscopicity, easy deliquescence dust, the surface of the filter bags may generate water or oil film and increase adhesion, although this will help to collect the dust, but will make cleaning difficult. Especially in the conditions with high temperature and high humidity, the condensation phenomenon caused by the external gas cooling effect. It can not only make the dust in the bag surface fouling or blockage, but also corrosion of structural materials, the dust running resistance increased, directly affects the normal operation of bag filter. In order to apply the special working conditions, prevent or mitigate dust bag pasting phenomenon, we need to do some improvements to make the work efficiency and extend service life of filter media.


Polyester dust collector filter bag parameter table

Product namePolyester Filter Bag
materialPET scrimFiberglass scrim
weight(g/m2)450500550600400450500550600
thickness(mm)1.61.82.02.21.41.61.82.02.2
Ventilation rate(m3/m2/min)330300250220350325285270230
Fracture strength(N/5*20cm)warp>750>750>800>800>1000>1000>1100>1100>1150
weft>1150>1200>1300>1400>1250>1300>1400>1500>1500
Elongation at break(%)warp<35<35<35<35<25<25<25<25<25
weft<55<55<55<55<45<45<45<45<45
Working temperature(ºC)<130<130<130<130<130<130<130<130<130
Instantaneous operating temperature(ºC)150150150150150150150150150
The fracture strain(Mpa/min)2.202.252.352.452.302.402.452.502.60
Acid resistancegoodgood
Alkali resistancemediummedium
Wear resistanceexcellentexcellent
Hydrolytic stabilitymediummedium
FinishAnti-acid resistance,PTFE membrane,heat setting,water and oil repllent...


Remark: We always provided the products customization service.

P84 / nomex / polyester /PTFE /FMS/PP needle punched high temperature filter felt cloth bag
Our P84 filter felt is made from LENZING company's INSPEC fibers .
Feature:

  1. high working temperature 260ºC ,But there is safe space to cope with outages and accidents, etc.
  2. Good chemical resistance In the past ten years, the filtration value of p84 filter bag for acid waste dust has been proved in waste incineration.
  3. Low reverse washing pressure and high efficiency of elastic desliming cakeTechnical data sheet

    Material fiber P84
    scrimP84
    weight500g/m2
    Thickness 2.2mm
    Tensile strength (N/5×20cm)warp≥1100N / 5cm
    weft≥1300N / 5cm
    Tensile elongation  (%)warp≤30%
    weft≤40%
    Air permeability (L/m2/S) (m3/m2·min)200-300 17



    260ºC hot air shrinkage warp< 1%
    260ºC hot air shrinkage weft< 1%
    Working temperature260ºC
    Peak temperature280ºC
    Finishing treatmentHeating ,singeing ,calendering
Application :At present, P84 filter bag has rich application experience has been obtained in gypsum plant, cement plant, waste incinerator, liquid fluidized bed boiler, coal-fired boiler and so on.

Aramid Filter Bag for Asphalt Plant Dust Collector

Hangzhou philis filter technology co.,ltd. has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.

Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Nomex ,P84 ,PTFE ,wool felt ,woven filter fabric and so on.

The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer's praise.


Q: ,What certifacation you have?

We have got ISO9001 and SGS certification

Q: How long is your delivery time?

A: Generally it is 5-10 working days if the goods are in stock. or it is 15-20 days if the goods are not in stock.It depends on the quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment≤1000USD, 100% in advance. Payment≥1000USD, 30% T/T in advance, balance before shippment.
 Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them.

Q:What should I do if I'm not satisfied with your product?
A:Please contact us as soon as possible and tell us where went wrong.We can only accept refund or exchange if there is any quality issue.


IF you have some interesting please contact us without any hesitate, we will reply you within 24 hours and welcome to have a visit to our factory for more further business and know each other better. We do have the keen interesting to cooperate with you near future.
