Brand Name: | RIQI |
MOQ: | 1 |
Supply Ability: | 10000PC/WEEK |
Low differential pressures, high dirt-retention capacity and a long service life.
Multi-layers Pleated depth filtration with maximum filtration area.
The scientific design for high flow rate.
Great chemical compatibility and acid-base resistance for liquid filtration
A wide range of fine filters which is suitable for all industries
Filters in water-treatment plants
Pre-filters in ultrapure water for the electronic industry
Drinking water for food and beverages
Process filters for acids and lyes
Filtration of inks for ink-jet applications
Liquid or gas filtration for biological products, compressed air .etc
Order information
Material of Constructions | HPMC-N | HPMC-T | HPMC-E |
Membrane Material | Hydrophilic nylon 66 membrane |
Hydrophilic PTFE membrane |
Hydrophilic PES membrane |
Support Material | Polypropylene | Polypropylene | Polypropylene |
Adapter Type | 222/226 | 222/226 | 222/226 |
Seal Rings | Silicone EPDM Viton | Silicone EPDM Viton | Silicone EPDM Viton |
Sterilization Method | 121ºC@100hours 140ºC@40hours | 121ºC@100hours 140ºC@40hours | 121ºC@100hours 140ºC@40hours |
Product code |
Retention ratings(µm) | Size(inch) | ID/OD(mm) | Max,differential pressure(bar) |
Max,temp(ºC) |
HPMC-N | 0.1/0.22/0.45/0.65/1 | 5'' 10'' 20'' 30'' 40'' | 28/69 |
4.0@21
2.4@80
|
80 |
HPMC-T | |||||
HPMC-E | 0.04/0.1/0.22/0.45/0.65 |
