Multifilament Woven Filter Cloth 750B Polypropylene Filter Fabric

Multifilament Woven Filter Cloth 750B Polypropylene Filter Fabric

Brand Name: RIQI
MOQ: 50m2
Price: 1.2 usd to 100usd
Supply Ability: 500pcs/day
Detail Information
Place of Origin:
Hangzhou
Certification:
ISO9001 SGS
Material:
Polypropylene
Usage:
Liquid Filter,dry Filter , Powder Filter Air Filter
Color:
White, Bule,black, Yellow
Application:
Chemical Industry, Sludge Dewatering,Waste Water Treatment, Solid Filter
Feature:
Sludge Treatment Industry,Filtration & Seperation
Packaging Details:
standard export packing
Supply Ability:
500pcs/day
Highlight:

Multifilament Woven Filter Cloth

,

Polypropylene Woven Filter Cloth

,

750B Polypropylene Filter Fabric

Product Description

Industrial woven Filter Cloth Polypropylene Multifilament 750B

Fiber Material: PP
Benefits:
Fine pores
High dimensional stability
Good abrasion resistance
Stable filtration performance
Wide range of filtration rating
Efficient fabric cleaning
Usage: Filter press machine, centrifuge machine, leaf filter, fluid bed dryer, rotary/horizontal disc filter, etc. It is applicable to chemical industry, dyes, non-ferrous metal, fermentation industry, etc.

Dewatering Sludge Multifilament/Monofilament Filter Cloth (filter bag) Chemical Function :

Property Polyester (PE) Polypropylene Nylon
Acid Excellent Excellent Excellent
Alkali Average Excellent Excellent
Electrical Conductivity Poor Good Average
Elongation 30%-40% Better than PE Poor
Recovery Excellent Slightly better than PE Poor
Abrasion Excellent Good Excellent
Heat Resistance 150 °C 90 °C 100 °C
Softening point 230 -240 °C 140 -150 °C 200 °C
Melting point 255 -265 °C 165 -170 °C 220 °C

Multifilament Woven Filter Cloth 750B Polypropylene Filter Fabric 0

Model no breaking strength(N/5*20CM) warp/weft
( /10cm)
thickness
(mm)
weight permeability fabric texture
521 2608/2050 214.8/150.8 0.79 302 216.5 twill
522 2104/1633 244/173 0.41 155 73.44 plain weave
534 2501/1894 193.6/100 0.99 368 41.2 plain weave
4212 staple fiber 2672/1342 236.4/123.2 1.34 389 85.2 twill
700A 3426.6/2819.4 204/106 0.7 350 117.9 plain weave
700B 4648/2866 118/114 0.59 280 254.2 twill
700AB 6865.4/416.7 378/235 1.15 580 82 twill +plain weave
750A(840A) 4466/2905 168/131 0.85 330 42 plain weave
750B(840B) 5234/3489 256/141 0.99 420 76 twill
750AB(840AB) 6718/5421 333.8/204.4 1.36 490 24.5 plain weave
840-1 5275/3948 252/146 0.9 440 45.5 twill
840-2 5928/4086 283/142 1 490 40.7 twill
840-3 6282/4858 311/134 1.11 520 20.2 twill
858 4418/3618 251/124 0.88 380 240.7 twill
4218 8568/5427 456/94 1.32 660 38.4 twill
4135 6797/2508 346/83 1.02 510 19.12 plain weave
4422 2643/1514 181/94 1.18 480 17.86 twill
1000A 5585/4089 204/102 0.85 435 9.83 plain weave
1000B 6636/1481 204/110 0.79 430 21.49 twill
1500-1 5628/3701 251/118 1.42 725 29.38 twill
108B 8721/4642 503/133 1.1 600 13.6 mixed weave
108C 8367/4797 504/177 1.03 600 22.96 satin weave
Polypropylene fiber 10398/ 448/141 0.9 900 8.2 heavy plain weave
conveyor belt 8006
