PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material

Certification
China Riqi ( Hangzhou ) Filter Technology Co., Ltd. certification
China Riqi ( Hangzhou ) Filter Technology Co., Ltd. certification
I'm Online Chat Now

PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material

PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material
PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material

Large Image :  PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material

Product Details:
Place of Origin: Hangzhou
Brand Name: RIQI
Certification: ISO9001 SGS

PPS P84 Nonwoven Filter Cloth , Anti Acidic Needle Felt Material

Description
Model NO.: PH00227 Working Temperature: 130
Anti Acidic: Good Anti Alkaline: Good
Width: 0 To 2.2 Meter Transport Package: Standard Export Packing
Specification: 1m X 1m X 1m Trademark: Philis
Origin: China HS Code: 5911900
Supply Ability: 5000PCS / Week Material: Polyester
Usage: Air Filter, Liquid Filter, Powder Filter, Solid Filter Type: Non-woven Filter
Hole Shape: Needle Punched Manufacturing Method: Manufacturing Cloth
Paper Type: Qualitative Samples: US$ 0/Square Meter 1 Square Meter(Min.Order) | Requ
Customization: Available | Customized Request
Highlight:

P84 Nonwoven Filter Cloth

,

PPS Nonwoven Filter Cloth

,

Anti Acidic Needle Felt Material

PPS, Aramid, PTFE, PE, Acrylic, P84 Nonwoven Needle Felt Filter Cloth Made in China



Product Description

Company Info.

Customer Question & Answer

Ask something for more details

Basic Info.

Model NO.
PH00227
Working Temperature
130
Anti Acidic
Good
Anti Alkaline
Good
Width
0 to 2.2 Meter
Transport Package
Standard Export Packing
Specification
1m x 1m x 1m
Trademark
philis
Origin
China
HS Code
5911900
Production Capacity
5000PCS / Week

Product Description

PPS,aramid ,PTFE,PE,Acrylic,P84 nonwoven needle felt filter cloth made in China
Application
:

The working environment of oil and gas such as blast furnace gas coal grinding dust and the cement plant coal grinding dust.

Working temperature (long-term) <120ºC;

 Working temperature (moment)150ºC

 Weight:  (g/m2)  500g

 Post-processing: singeing, calendering ,heat setting ,
Anti-static fiber



Feature

Under the condition of normal flue gas temperature, bag filter for dust filter bag and heat-resistant requirements under 150 ºC, and suitable for dust is not completely dry, and the situation of a certain humidity,
It is necessary to adopt waterproof and anti-oil treatment, Avoid the hydrolysis of the filter cloth, and improve the dust removal of the filter cloth.

The rupture strength (longitude)1200N / 5 by 20cm
The rupture strength (latitude) 1200N / 5 by 20cm
PPS, Aramid, PTFE, PE, Acrylic, P84 Nonwoven Needle Felt Filter Cloth Made in China

PPS, Aramid, PTFE, PE, Acrylic, P84 Nonwoven Needle Felt Filter Cloth Made in China

Philis filter polyester needle punched felt is made from 1-2.5D PE filber Weaving reinforced substrates with High strength and low elongation Yarn,Through needle punched reinforcement and finishing-treatment process.The product has the special characteristics of high porosity, good permeability, acid resistance and moderate alkalinity of ordinary felt filter cloth.And very good wear resistance.One of the mostly used kinds of felt filter material.
Weight from 350gsm to 800g/m2 thickness from 1mm to 4mm .
 Finishing treatment : calendering , singeing,heating , PTFE coated. It has the characteristics of stable size, easy cleaning, long service life and so on.

Technical data sheet

material Polyester fiber   Polyester fiber
scrim polyester   polyester
weight 500g/m2   550g/m2
Thickness 1.70mm   2.00mm
Tensile strength   warp ≥11500N / 5cm   ≥1200N / 5cm
  weft ≥1500N / 5cm   ≥1600N / 5cm
Tensile elongation (%)   warp ≤30%   ≤30%
  weft ≤45%   ≤45%
Air permeabilithy(m3/m2·min) 14   12
130ºC Dry heat shrinkage warp < 1%   < 1%
130ºC Dry heat shrinkage weft < 1%   < 1%
Working temperature 130deg ºC   130deg ºC
Peak temperature 150deg ºC   150deg ºC
Finishing treatment Heating,singeing , calendering   Heating,singeing , calendering


Application : Mainly used in furniture, ceramics, powder coatings, batteries, cement, metallurgy, chemical, building materials, smelting, power generation, machinery, mines, petroleum, medicine, dyes, food,Grain processing and other manufacturers dust collect .


PPS, Aramid, PTFE, PE, Acrylic, P84 Nonwoven Needle Felt Filter Cloth Made in China

Hangzhou philis filter technology co.,ltd. has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.

Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Nomex ,P84 ,PTFE ,woven filter fabric and so on.

The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer's praise.
Q: ,What certifacation you have?

We have got ISO9001 and SGS certification

Q: How long is your delivery time?

A: Generally it is 5-10 working days if the goods are in stock. or it is 15-20 days if the goods are not in stock.It depends on the quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment≤1000USD, 100% in advance. Payment≥1000USD, 30% T/T in advance, balance before shippment.
 Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them.

Q:What should I do if I'm not satisfied with your product?
A:Please contact us as soon as possible and tell us where went wrong.We can only accept refund or exchange if there is any quality issue.


IF you have some interesting please contact us without any hesitate, we will reply you within 24 hours and welcome to have a visit to our factory for more further business and know each other better. We do have the keen interesting to cooperate with you near future.
