Non Woven Industrial Polyester Needle Punched Filter Cloth for Dust Collector Bag 400gsm 450gsm 500gsm 550gsm 600gsm

Large Image : Non Woven Industrial Polyester Needle Punched Filter Cloth for Dust Collector Bag 400gsm 450gsm 500gsm 550gsm 600gsm

Product Details:

Place of Origin:	China
Brand Name:	RQ

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	1.1usd to 25usd/m2
Packaging Details:	standard export packing
Delivery Time:	5-15days
Supply Ability:	5000m2/day

Contact Now

Non Woven Industrial Polyester Needle Punched Filter Cloth for Dust Collector Bag 400gsm 450gsm 500gsm 550gsm 600gsm

Description

Material:	Polyester , Nomex , Aramid , PPS , PTFE , Fiberglass , Acrylic	Weight:	300gsm To 900gsm
Feature:	High Temperature Resistance, Waterproof, Breathable	Thickness:	1.8mm To 2.5mm
Sizes:	Custiomized	Width:	1meter To 2.2 Meters
Finishing:	Heat Set, PTFE Coating, Singed/glazed Finish	Function:	Dust Collection

Non-woven dust filter needled felt

is used non-woven needle punched process to make fiber staggered, space distribution uniform fine fiber cloth. the regular fiber: PE, PP, Acrylic, Nomex, PPS, Fiberglass, P84,PTFE. With the heat setting, singeing, water & oil dipping, or PTFE membrane on the surface finish treatment, it makes the needle felt surface smooth, and not easy to be blocked by dust.
The fiber in Filtration needle felt has the three-dimensional structure. This structure is conducive to form the dust layer, dust collection effect stable.

Its efficiency is higher than general woven filter material.The application of the felt is very extensive like cement, waste incineration, power plant, coal burning boiler, foundry, metallurgical industry, asphalt, pharmacy, food industry, with strong resistance to chemical stability. It can filter normal temperature or high temperature gas, and the gas with acid and alkali corrosive.

			Material

			Polyester Filter Cloth

			Base Fabric

			Normal

			Weight (g/m2)

			450

			500

			550

			600

			Thickness (mm)

			1.6

			1.8

			2

			2.2

			Air Permeability (L/m2/S)

			330

			300

			250

			220

			Break Elongation (N/5x20cm)

			Warp

			>750

			>750

			>800

			>800

			Weft

			>1150

			>1200

			>1300

			>1400

			Liner Strinkage (%)

			Warp

			<35

			<35

			<35

			<35

			Weft

			<55

			<55

			<55

			<55

			Break Strength (Mpa/min)

			2.2

			2.25

			2.35

			2.45

			Operating Temperature (℃)

			≤130

			≤130

			≤130

			≤130

			Instant Temperature (℃)

			150

			150

			150

			150

			Resistance to Acid

			Good

			Resistance to Alkali

			Fair

			Resistance to Abrasion

			Excellent

			Resistance to Hydrolysis

			Fair

			Mechanical Finish

			Singed, Glazed, Heat-Seting

Technical data sheet

			material
			Polyester fiber

			Polyester fiber

			scrim
			polyester

			polyester

			weight
			500g/m2

			550g/m2

			Thickness
			1.70mm

			2.00mm

			Tensile strength

			warp
			≥11500N / 5cm

			≥1200N / 5cm

			weft
			≥1500N / 5cm

			≥1600N / 5cm

			Tensile elongation (%)

			warp
			≤30%

			≤30%

			weft
			≤45%

			≤45%

			Air permeabilithy(m3/m2·min)
			14

			12

			130ºC Dry heat shrinkage warp
			< 1%

			< 1%

			130ºC Dry heat shrinkage weft
			< 1%

			< 1%

			Working temperature
			130deg ºC

			130deg ºC

			Peak temperature
			150deg ºC

			150deg ºC

			Finishing treatment
			Heating,singeing , calendering

			Heating,singeing , calendering

Applicati
Applicatiion
