Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric

Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric
Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric

Large Image :  Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric

Product Details:
Place of Origin: Hangzhou
Brand Name: RIQI
Certification: ISO9001 SGS
Payment & Shipping Terms:
Minimum Order Quantity: 50m2
Packaging Details: standard export packing
Delivery Time: 5-15days

Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric

Description
Material: Fiberglass Weight: 350gsm To 800gsm
Type: Woven Application: Industrial, Dust Collect, Air Purifier/Cabin Air Filte
Feature: High Temperature, High Efficency, Filtration & Seperation
High Light:

Woven Fiberglass Filter Cloth

,

Membrane Fiberglass Filter Cloth

,

PTFE Dust Collector Filter Fabric

High Efficiency Dust Collection PTFE Finished PTFE Membrane woven Fiberglass Filter Cloth



PRODUCTS SPECIFICATION

Type
PTFE MEMBRANE
Component Non-Alkaline Fiberglass
Weave Pattern Double Twill
Processing Mode PTFE Finished
Weight 800±20 g/m2 22.12±0.74 oz/yd2
Air Permeability 2~5cm3/cm2/s 4~10 cfm/sq ft
Warp Tensile Strength 2000 N/25mm 450 lbf/inch
Weft Tensile Strength 2000N/25mm 450 lbf/inch
Loss on Ignition >10% >10%
Continuously running temperature 260ºC 500ºF
Instantaneous maximum temperature 280ºC 536ºF
Corrosion resistance excellent



Baghouse Filtration Dust Filter bags Fiberglass Filter bags , 850GSM Fiberglass Cloth Filter Bags

Fiberglass Filter Bags Specification:
1. Material : Fiberglass staple fiber
2. Scrim: with fiberglass staple yarn
3. Width:≤2.2m
4. Thickness:2.3-2.7mm
5. Weight:800-900g/m2 ±10%
6. Temperature (ºC): Continue: 240, Instant: 280

Fiberglass Filter Bags Applications :
Fiberglass non woven filter media bags applications ranges in asphalt plant, incinerator, metallurgy, cement carbon black, liquid boiler, coal fire boiler dust filtration.

Fiberglass Filter Bags Advantages:
1. Good Temperature-Resistance. Max. Temp. 280 degree C.
2. High Filtration Efficiency: up to 99.9%
3. Excellent performance in Anti corrosion.
4.Fiberglass filters is the first choice for incinerator smoke , smoke in industries like metallurgy, cement , carbon black, liquid boiler, coal fire boiler.
5. Longer working time: more than 36 months.
6. Variety of finish treatments : Coating PTFE Membrane,PTFE Impregnation
7. Good heat resistance, flame retardant, anti-corrosion effect.
8 . Used in dust filtration of high temperature, high acidity, high alkalinity, fine high
temperature, collection of valuable metal powder , high adhesive property etc.
9. Customized by order.
With rich practical experience and working R&D team, we can design and develop kinds of filter media to satisfy the complex and diverse working conditions.
10. Advanced production lines: Complete testing and testing methods are the assurance to the products' quality.


Cement plant,steel plant(blast furnace gas,coking,converter,lime kiln),coal-fired boiler,biomass power generation,chemical plant etc.

Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric 0

Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric 1

Membrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric 2




High Efficiency Dust Collection PTFE Finished PTFE Membrane Fiberglass Filter ClothMembrane woven Fiberglass Filter Cloth , PTFE Dust Collector Filter Fabric 4



Nonwovern dust filter bag

Continuous

Temperature

Peak

Temperature

Description

Resistance to

Acids

Resistance to

Alkalis

Resistance to

Oxidation

PH Value
Polypropylene 90ºC 100ºC PP excellent excellent restricted 1-14
Acrylic 125ºC 140ºC AC good good good 3-11
Polyester 130ºC 150ºC PE restricted moderate good 4-12
Polyphenylen sulfide 190ºC 200ºC PPS excellent excellent moderate 1-14
Nomex 204ºC 250ºC Nomex good excellent good 3-14
Polysulfonamide 250ºC 300ºC PSA excellent excellent excellent 3-14
Polymide 260ºC 300ºC P84 good moderate good 3-13
Polytertrafluoroethylene 250ºC 280ºC PTFE excellent excellent excellent 1-14
Yadi 150ºC 160ºC Yadi excellent excellent excellent 3-13
Glassfiber 260ºC 300ºC BQ good good good 3-11
