PPS Fiberglass Filter Cloth Long Service Life For Metallurgy

PPS Fiberglass Filter Cloth Long Service Life For Metallurgy
PPS Fiberglass Filter Cloth Long Service Life For Metallurgy PPS Fiberglass Filter Cloth Long Service Life For Metallurgy PPS Fiberglass Filter Cloth Long Service Life For Metallurgy

Large Image :  PPS Fiberglass Filter Cloth Long Service Life For Metallurgy

Product Details:
Place of Origin: Hangzhou
Brand Name: RIQI
Certification: ISO9001 SGS

PPS Fiberglass Filter Cloth Long Service Life For Metallurgy

Description
Specification: 50m/roll Or 100m /roll Trademark: Philis
Origin: China Supply Ability: 10000m/Week
Material: Polyester, PPS, Fiberglass, Fms, Nomex, PTFE Usage: Air Filter, Powder Filter
Type: Filter Felt Hole Shape: Square
Manufacturing Method: Manufacturing Cloth Transport Package: Standard Export Package
Samples: US$ 5/Square Meter 1 Square Meter(Min.Order) | Requ Customization: Available | Customized Request
High Light:

Metallurgy Fiberglass Filter Cloth

,

PPS Fiberglass Filter Cloth

,

pps filter bags

Fiberglass Needle Felt / Glassfiber Filter Fabric / Fiberglass Nonwoven Dust Bag for Metallurgy



Product Description

Company Info.

Customer Question & Answer

Ask something for more details

Basic Info.

Specification
50m/roll or 100m /roll
Trademark
philis
Origin
China
Production Capacity
10000m/Week

Product Description

fiberglass needle felt / glassfiber filter fabric / fiberglass nonwoven dust bag for metallurgy


Quick Detail:

dust filter cloth

1. Non-toxic and odorless
2. Long service life
3. Good stiffness, easy to pleat
4. High air permeability
5. High dust holding


Description:

Excellent resistant to hydrolysis, acids and alkalies.

good air permeability

Lower fiber release, Lower density,High mechanical characteristics



Technical Specification:



Nonwovern dust filter bag

Continuous

Temperature

Peak

Temperature

Description

Resistance to

Acids

Resistance to

Alkalis

Resistance to

Oxidation

PH Value
Polypropylene 90ºC 100ºC PP excellent excellent restricted 1-14
Acrylic 125ºC 140ºC AC good good good 3-11
Polyester 130ºC 150ºC PE restricted moderate good 4-12
Polyphenylen sulfide 190ºC 200ºC PPS excellent excellent moderate 1-14
Nomex 204ºC 250ºC Nomex good excellent good 3-14
Polysulfonamide 250ºC 300ºC PSA excellent excellent excellent 3-14
Polymide 260ºC 300ºC P84 good moderate good 3-13
Polytertrafluoroethylene 250ºC 280ºC PTFE excellent excellent excellent 1-14
Yadi 150ºC 160ºC Yadi excellent excellent excellent 3-13
Glassfiber 260ºC 300ºC BQ good good good 3-11


Glass fiber filter felt Technical parameters

Weight ≥ 850g/m²
Material fiberglass/ fiberglass fabric
Thickness 2.0-2.8mm
Air permeability 8-15m³/m².min
Warp tensile foce >1500N/5X20cm
Weft tensile foce >1500N/5X20cm
Warp elongation <10%
Weft elongation <10%
Continuous service temperature <260ºC instantaneous 280ºC
Finish Teflon treatment


Feature:

glass fiber needle felt is one kind of high temperature resistant filter material with reasonable structure and excellent performance,it could be high temperature resistant,anti-abrasion,stable size,little elongation shrinkage ratio,high intension,also ultimate fiber of felt layer fiber,three dimensional micro pore structure,high porosity,small filter resistance to gas,it has higher speed and efficiency,Comparing with other high temperature resistant chemical fiber felt,it has the advantage of lower price,high temperature resistant,but due to high resistance, filtering efficiency is lower


Notices:

1. Materials avaliable: polyester, polypropylene,Nomex , PPS, PTFE, P84, Acrylic , glassfiber .

2. construction: welded or sewn

3. collar type: steel ring or plastic ring

4. finishing treatment: singed, calendared, heat set

5. Size available: standard and custom size.


Applications:

1. Air filters capture pollen, allergens, mold spores, and other microscopic particles to reduce symptoms and help everyone breathe easier.

2. medical filters made from nonwovens are key in any operating room to keep out pathogens, bacteria or microbes that might otherwise contaminate a sterile environment.

3. Oil filters are an important component in your car. The nonwoven fabrics in the filter help remove contaminants from the engine oil, hydraulic oil, trasmission oil and lubricating oil.

4. Automotive engine air intake filter helps automobile engines run at the highest efficiency,optimum airflow helps ensure engines run most effectively, which reduces fuel waste.

5. Filters for industrial filtration are used for dust produced in processing industries such as grinding, separation, brushing, transportation, drying, incinerating, etc.



Fiberglass Needle Felt / Glassfiber Filter Fabric / Fiberglass Nonwoven Dust Bag for Metallurgy


Fiberglass Needle Felt / Glassfiber Filter Fabric / Fiberglass Nonwoven Dust Bag for Metallurgy

Fiberglass Needle Felt / Glassfiber Filter Fabric / Fiberglass Nonwoven Dust Bag for Metallurgy


FAQ

1. May I get samples?

Yes,

For OEM sample, usually takes about 5~15 days, it depends on design and technique.


2. Can you make my logo on package?

Of course! You only need provide us your original logo file or clear picture, so we can make it.

3. What is the payment method?

Bank transfer (T/T), Western Union, Money gram, L/C, paypal


4. How long production takes?

It is usually in 5~7 days after getting your payment and all the details confirmed.
