Fiberglass Needle Felt / Glassfiber Filter Fabric / Fiberglass Nonwoven Dust Bag for Metallurgy
Quick Detail:
dust filter cloth
1. Non-toxic and odorless
2. Long service life
3. Good stiffness, easy to pleat
4. High air permeability
5. High dust holding
Description:
Excellent resistant to hydrolysis, acids and alkalies.
good air permeability
Lower fiber release, Lower density,High mechanical characteristics
Technical Specification:
|
Nonwovern dust filter bag |
Continuous Temperature |
Peak Temperature |
Description |
Resistance to Acids |
Resistance to Alkalis |
Resistance to Oxidation |
PH Value | ||||||
| Polypropylene | 90ºC | 100ºC | PP | excellent | excellent | restricted | 1-14 | ||||||
| Acrylic | 125ºC | 140ºC | AC | good | good | good | 3-11 | ||||||
| Polyester | 130ºC | 150ºC | PE | restricted | moderate | good | 4-12 | ||||||
| Polyphenylen sulfide | 190ºC | 200ºC | PPS | excellent | excellent | moderate | 1-14 | ||||||
| Nomex | 204ºC | 250ºC | Nomex | good | excellent | good | 3-14 | ||||||
| Polysulfonamide | 250ºC | 300ºC | PSA | excellent | excellent | excellent | 3-14 | ||||||
| Polymide | 260ºC | 300ºC | P84 | good | moderate | good | 3-13 | ||||||
| Polytertrafluoroethylene | 250ºC | 280ºC | PTFE | excellent | excellent | excellent | 1-14 | ||||||
| Yadi | 150ºC | 160ºC | Yadi | excellent | excellent | excellent | 3-13 | ||||||
| Glassfiber | 260ºC | 300ºC | BQ | good | good | good | 3-11 | ||||||
Glass fiber filter felt Technical parameters
| Weight | ≥ 850g/m² |
| Material | fiberglass/ fiberglass fabric |
| Thickness | 2.0-2.8mm |
| Air permeability | 8-15m³/m².min |
| Warp tensile foce | >1500N/5X20cm |
| Weft tensile foce | >1500N/5X20cm |
| Warp elongation | <10% |
| Weft elongation | <10% |
| Continuous service temperature | <260ºC instantaneous 280ºC |
| Finish | Teflon treatment |
Feature:
glass fiber needle felt is one kind of high temperature resistant filter material with reasonable structure and excellent performance,it could be high temperature resistant,anti-abrasion,stable size,little elongation shrinkage ratio,high intension,also ultimate fiber of felt layer fiber,three dimensional micro pore structure,high porosity,small filter resistance to gas,it has higher speed and efficiency,Comparing with other high temperature resistant chemical fiber felt,it has the advantage of lower price,high temperature resistant,but due to high resistance, filtering efficiency is lower
Notices:
1. Materials avaliable: polyester, polypropylene,Nomex , PPS, PTFE, P84, Acrylic , glassfiber .
2. construction: welded or sewn
3. collar type: steel ring or plastic ring
4. finishing treatment: singed, calendared, heat set
5. Size available: standard and custom size.
Applications:
1. Air filters capture pollen, allergens, mold spores, and other microscopic particles to reduce symptoms and help everyone breathe easier.
2. medical filters made from nonwovens are key in any operating room to keep out pathogens, bacteria or microbes that might otherwise contaminate a sterile environment.
3. Oil filters are an important component in your car. The nonwoven fabrics in the filter help remove contaminants from the engine oil, hydraulic oil, trasmission oil and lubricating oil.
4. Automotive engine air intake filter helps automobile engines run at the highest efficiency,optimum airflow helps ensure engines run most effectively, which reduces fuel waste.
5. Filters for industrial filtration are used for dust produced in processing industries such as grinding, separation, brushing, transportation, drying, incinerating, etc.
