P84 Media Needle Aramid Fiber Cloth 100m / roll Customization

P84 Media Needle Aramid Fiber Cloth 100m / roll Customization
P84 Media Needle Aramid Fiber Cloth 100m / roll Customization P84 Media Needle Aramid Fiber Cloth 100m / roll Customization P84 Media Needle Aramid Fiber Cloth 100m / roll Customization

Large Image :  P84 Media Needle Aramid Fiber Cloth 100m / roll Customization

Product Details:
Place of Origin: Hangzhou
Brand Name: RIQI
Certification: ISO9001 SGS

P84 Media Needle Aramid Fiber Cloth 100m / roll Customization

Description
Supply Ability: 10000m/Week Specification: 50m/roll Or 100m /roll
Trademark: Philis Origin: China
Material: Polyester, PPS, Fiberglass, Fms, Nomex, PTFE Usage: Air Filter, Powder Filter
Type: Filter Felt Hole Shape: Square
Manufacturing Method: Manufacturing Cloth Transport Package: Standard Export Package
Samples: US$ 5/Square Meter 1 Square Meter(Min.Order) | Requ Customization: Available | Customized Request
High Light:

Media Needle Aramid Fiber Cloth

,

P84 Aramid Fiber Cloth

,

100m / Roll aramid fibre cloth

Filter Media Needle Felt P84 Fabric Non Woven Aramid Fabric



Product Description

Company Info.

Customer Question & Answer

Ask something for more details

Basic Info.

Specification
50m/roll or 100m /roll
Trademark
philis
Origin
China
Production Capacity
10000m/Week

Product Description

Filter Media Filter Felt Needle Felt P84 Fabric Non Woven Aramid Fabric


Quick Detail:

dust filter cloth

1. Non-toxic and odorless
2. Long service life
3. Good stiffness, easy to pleat
4. High air permeability
5. High dust holding


Description:

Excellent resistant to hydrolysis, acids and alkalies.

good air permeability

Lower fiber release, Lower density,High mechanical characteristics



Technical Specification:



Nonwovern dust filter bag

Continuous

Temperature

Peak

Temperature

Description

Resistance to

Acids

Resistance to

Alkalis

Resistance to

Oxidation

PH Value
Polypropylene 90ºC 100ºC PP excellent excellent restricted 1-14
Acrylic 125ºC 140ºC AC good good good 3-11
Polyester 130ºC 150ºC PE restricted moderate good 4-12
Polyphenylen sulfide 190ºC 200ºC PPS excellent excellent moderate 1-14
Nomex 204ºC 250ºC Nomex good excellent good 3-14
Polysulfonamide 250ºC 300ºC PSA excellent excellent excellent 3-14
Polymide 260ºC 300ºC P84 good moderate good 3-13
Polytertrafluoroethylene 250ºC 280ºC PTFE excellent excellent excellent 1-14
Yadi 150ºC 160ºC Yadi excellent excellent excellent 3-13
Glassfiber 260ºC 300ºC BQ good good good 3-11


Specification

Compositions P84/P84 scrim P84 / glass scrim
Weight (g/m2) 450 500 550 800 850 900
Thickness (mm) 2.0 2.2 2.4 2.5 2.8 3.0
Air permeability (m2m2/min) 19 15 12 16 13 10
Tensile strength (N/5×20cm) Warp 650 700 800 1800 1800 1800
Weft 1150 1200 1300 1800 1800 1800
Tensile Elongation (%) Warp <35 <35 <35 <10 <10 <10
Weft <55 <55 <55 <10 <10 <10
Working Temperature(°C) Continues ≤260 ≤260
Instant 300 300
Anti-acid Excellent Excellent
Anti-alkali Medial Medial
Anti-abrasion Excellent Excellent
The stability of water solution Medial Medial
Finishing treatment Singeing,High temperature hot pressing Singeing,High temperature hot pressing



Feature:

P84 Felt filter Media provide a unique and cost effective solution for many tough industrialbaghouse applications. Versatile and efficient,P84 usage ranges from minerals processing, low acid coal fired boilers, asphalt / hot mix plants, to soil remediation facilities.P84 fibers are needled into filtration quality felts to be sewn into filter bags suitable for use in pulse jet style baghouses. The unique tri-lobal fiber structure of P84 provides customers with high efficiency filtration, low pressure drop, and reduced cleaning energy.


Notices:

1. Materials avaliable: polyester, polypropylene,Nomex , PPS, PTFE, P84, Acrylic , glassfiber .

2. construction: welded or sewn

3. collar type: steel ring or plastic ring

4. finishing treatment: singed, calendared, heat set

5. Size available: standard and custom size.


Applications:

1. Air filters capture pollen, allergens, mold spores, and other microscopic particles to reduce symptoms and help everyone breathe easier.

2. medical filters made from nonwovens are key in any operating room to keep out pathogens, bacteria or microbes that might otherwise contaminate a sterile environment.

3. Oil filters are an important component in your car. The nonwoven fabrics in the filter help remove contaminants from the engine oil, hydraulic oil, trasmission oil and lubricating oil.

4. Automotive engine air intake filter helps automobile engines run at the highest efficiency,optimum airflow helps ensure engines run most effectively, which reduces fuel waste.

5. Filters for industrial filtration are used for dust produced in processing industries such as grinding, separation, brushing, transportation, drying, incinerating, etc.


Filter Media Needle Felt P84 Fabric Non Woven Aramid Fabric

Filter Media Needle Felt P84 Fabric Non Woven Aramid Fabric


Filter Media Needle Felt P84 Fabric Non Woven Aramid Fabric



FAQ

1. May I get samples?

Yes,

For OEM sample, usually takes about 5~15 days, it depends on design and technique.


2. Can you make my logo on package?

Of course! You only need provide us your original logo file or clear picture, so we can make it.

3. What is the payment method?

Bank transfer (T/T), Western Union, Money gram, L/C, paypal


4. How long production takes?

It is usually in 5~7 days after getting your payment and all the details confirmed.
